Model: CDU980E
$208.05
In-Stock
$20.70
Only 3 In-Stock
Features
Style
Primary
GPH
4200 Gallons
Switch Type
Vertical
- Offers Years of Reliable, Trouble-free Operation
- Cast Iron housing
- Corrosion-resistant steel column
- Stainless steel fasteners
- 1/2 HP Heavy-Duty, Air-Cooled Motor
- Thermally protected to prevent overheating
- Reinforced Poly-Carbonate Impeller
- Reliable pumping year after year
- Adjustable Vertical Float
- Easily change the operating cycle to fit your application
- High Capacity 1 1/2" NPT discharge
- Will replace most submersible sumps without any plumbing changes
- Top Suction Design
- Filters Debris and Prevents Clogging
- 2 Year Limited Warranty
Specifications
SPV800
Base
Min Sump Basin Size
14 Inch
Motor
Voltage
120 Volt
Running Amps
5.3
Thermal Protection
Yes
Power Cord Length
8 Feet
Oil Free Motor
Yes
Pump
Housing Material
Cast Iron
Handles Solids
No
Float Type
Vertical Float
GPH @ 0 feet
4200
GPH @ 5 feet
4200
GPH @ 10 feet
3800
GPH @ 15 feet
2900
GPH @ 20 feet
1500
Discharge Port Size
1-1/2 Inch
Check Valve Included
No
Float On
Adjustable
Float Off
Adjustable
Manual Override
No
Engine
Horsepower
.5 HP
Overview
Weight
27 Pounds
Consumer Warranty
2 Years
Product Length
8 Inches
Product Width
8 Inches
Product Height
34 Inches
UPC
040066100429
Reviews
(41)
Wayne SPV800 Reviews & Ratings
Customer Photos and Videos
Customer Rating
4.66
(41 Ratings)
97% recommend this product
5
(34)
(34)4(4)
(4)3(1)
(1)2(0)
(0)1(2)
(2)
Sump Pump
By Lloyd B.
East Moline, Illinois
Purchased 01/08/2016 |
Review Posted 03/16/2016
Sad to say that I have not installed the sump pump yet, but the quality looks great and I am sure it will work fine.
Lloyd B. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
Quiet
By William H.
Willoughby Hills, Ohio
Purchased 02/21/2016 |
Review Posted 03/14/2016
I installed the Wayne pedestal pump as a replacement. It is much quieter than the old pedestal pump.
William H. Recommends This
Was this review helpful?
Rating Breakdown
4/5
4/5
5/5
4/5
Wayne pump
By Robert P.
Berkley, Massachusetts
Purchased 01/08/2016 |
Review Posted 02/26/2016
We installed this pump in an old well we have in our basement that floods over with heavy rain and it works great! This is a wonderful product and we're happy we bought it.
Robert P. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Buy the REAL DEAL from THE REAL DEAL!!
By Joseph P.
Elm Grove, Wisconsin
Purchased 01/27/2016 |
Review Posted 02/17/2016
I went to H D bought what looked like a Wayne, (at the time I forgot what I had at home that needed replacement), for $179.00. When I pulled the real Wayne out and replaced with the H D lookalike my first thought was wow the H D version weighs a lot less, that was the first sighn. Well the flotation device broke off, it did not pump well and after about a week the fake H D version began to fail. I found Sump Pumps Direct, they assisted me on a call, sent me a Wayne pump in 24 hours it arrived! Very superior, works great and was only $149.00 delivered! Thanks for your help!!
Joseph P. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Impressed
By Gordon C.
Waterford, Michigan
Purchased 11/27/2015 |
Review Posted 12/20/2015
Bought this pump about 2 weeks ago after my 1 year old, just-installed Ridgid started making awful noise at the 15 minute mark. This Wayne pump seems quite substantial, and runs very quietly. Time will tell, but so far, I'm very happy with it!
Gordon C. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
4/5
Great Pump
By David B
Eden, Maryland
Purchased 10/06/2015 |
Review Posted 10/28/2015
Replaced a 12 year old Craftsman that was still running. The new pump runs good but won't see service till late winter into spring.
David B Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
Finally swapped it out with the threat of a Hurricane coming
By Ken G.
Gilbertsville, Pennsylvania
Purchased 06/26/2015 |
Review Posted 10/03/2015
Replaced a tired sump pump with this model. Built better and raised GPM's from the old.
Like this pump much better.
Like this pump much better.
Ken G. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
4/5
5/5
Wayne spv800
By Bradley J.
Carlisle, Pennsylvania
Purchased 07/25/2015 |
Review Posted 08/23/2015
I was very happy with my purchase, pump works very good, would buy from you again, fast shipping and good service. Thank you.
Bradley J. Recommends This
Was this review helpful?
Rating Breakdown
5/5
4/5
5/5
5/5
Wayne SPV800 - 1/2 HP Cast Iron Pedestal Pump w/ Vertical Float
By Duane G.
Salt Lake City, Utah
Purchased 06/28/2015 |
Review Posted 07/27/2015
Works great. Replaced one that had run for over 30 years. The new Wayne shows the old pump just was not working. Easy to set up, clear instructions. Float adjustment took a few days to get set to pump at right amount, not tricky, just requires some thought. Arrived undamaged and on time. Ordered online and paid via paypal and when the order didn't appear online I called customer service and they assured me the pump shipped and indeed the pump was shipped.
Have had pump installed for about a month now. I wanted to make sure pump worked properly before I reviewed. Bought this pump because it was the BEST according to reviews and it sure appears to be problem free so far !! I would purchase this pump again and from this company. So far great working pump for my needs. Hopefully it works for another 30 years like the old pump.
Have had pump installed for about a month now. I wanted to make sure pump worked properly before I reviewed. Bought this pump because it was the BEST according to reviews and it sure appears to be problem free so far !! I would purchase this pump again and from this company. So far great working pump for my needs. Hopefully it works for another 30 years like the old pump.
Duane G. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
At First I Thought This Pump Was Great - Now ......
By Robin T.
Baldwinsville, New York
Purchased 05/01/2015 |
Review Posted 05/23/2015
After I installed the Wayne pedestal (replacing my 5 year old Rigid) I was amazed at how quiet it ran. It was so quiet I was going to order a second pump to have as a ready replacement. Two days later the pump started making a much louder noise, vibration of the impeller I believe. During the Spring my pump will run every 6 minutes for 30 seconds, so the noise can be highly noticeable. Yes it pumps fine, but no quieter than my Rigid. Oh well.
Robin T. Recommends This
Was this review helpful?
Rating Breakdown
4/5
4/5
4/5
4/5
