Little Giant 9SN-CIA-RF - 4/10 HP Cast Iron Sewage Pump (2") w/ Piggyback Tether Float
Model:
509204
+
Share This Product
Similar Products
$302.00
$479.00
$299.00
$379.00
$438.88
$419.00
$448.00
Recommended Accessories
Expert Recommended Accessories
Selected by Jim, our Expert
Optional Accessories
5
Sludge Alarm - Indoor / Outdoor Sewage / Septic High Water Alarm (120V) w/ Sludge Boss 16-Foot Float
Model: SA-120V-1L-16SB
$185.99
Factory-Direct
Model: SA-120V-1L-16SB-WIFI
$274.00
Only 1 In-Stock
Model: 14942914
$61.00
Only 2 In-Stock
$123.00
Factory-Direct
Model: 30-0048
$48.00
In-Stock
Features
Style
Sewage Pump
GPH
6600 Gallons
Switch Type
Piggy-Back Tether
- Continuous Duty Rated Automatic Submersible Sewage Pump
- Designed for the tough demanding tasks for wastewater removal
- Epoxy Coated Cast Iron Pump Housing w/ 2" Discharge
- Minimizes rust & corrosion to extend overall pump life
- 4/10 HP PSC Motor w/ Thermal Overload Protection
- Energy saving design w/ low amp draw (8.5-Amps full load)
- Cooler running motor which extends the life of the pump
- Piggyback Tethered Float Switch
- Switch can be bypassed to run pump manually in an emergency
- Epoxy Coated Cast Iron Volute w/ Vortex Style Nylon Impeller
- Non-clogging design passes up to 2" spherical solids
- Nitrile Mechanical Shaft Seal w/ Carbon & Ceramic Faces
- Assures maximum protection is harsh wastewater condtions
- Upper Sintered Sleeve Bearings & Lower Ball Bearings
- Minimizes friction while providing smooth & quiet operation
- Stainless Steel Screws, Bolts & Handle
- Never worry about sheet metal parts to rust or corrode
- 20-Foot SJTW Power Cord
- 20' Max Shutoff Head
- 2-Year Limited Warranty
California residents see
Warning: This product can expose you to chemicals including Carbon black (airborne, unbound particles of respirable size) which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov
Specifications
509204
Base
Min Sump Basin Size
18 Inch
Motor
Voltage
120 Volt
Running Amps
8.5
Thermal Protection
Yes
Power Cord Length
20 Feet
Oil Free Motor
No
Pump
Housing Material
Cast Iron
Solids Handling Size
2 inch
Float Type
Piggy-Back Tether Switch
GPH @ 0 feet
6600
GPH @ 5 feet
6600
GPH @ 10 feet
4200
GPH @ 15 feet
1800
Discharge Port Size
2 Inch
Check Valve Included
No
Float On
9-14 Inches
Float Off
2-6 Inches
Manual Override
Yes
Engine
Horsepower
.4 HP
Overview
Weight
36.5 Pounds
Consumer Warranty
2 Years
Product Length
11.64 Inches
Product Width
6.8 Inches
Product Height
11.4 Inches
UPC
010121140035
