Goulds PE-Series - 4/10 HP Cast Iron Effluent Pump (Non-Automatic)

Model:

PE41M

Write A Review
Add to Cart for Price
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
In-Stock
Ships Monday, Dec 23rd
Shipping to60601

Goulds PE-Series - 4/10 HP Cast Iron Effluent Pump (Non-Automatic)
Goulds PE-Series - 4/10 HP Cast Iron Effluent Pump (Non-Automatic)
Model: PE41M
Add to Cart for Price
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

Sump Pumps Direct expert image
Expert Recommended Accessories Selected by Jim, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Style

Effluent

GPH

3660 Gallons

Switch Type

None

  • ***NON-AUTOMATIC - Requires Float Switch or Controller***
  • Goulds PE Series Submersible Effluent Pump
  • Ideal for mound, dosing & low pressure pipe (LPP) systems
  • Cast Iron Pump Body
  • Robust design provides maximum heat dissipation
  • 4/10 HP PCS Motor
  • Oil-filled and thermally protected w/ auto reset
  • Designed for Continuous Operation
  • Can be operated continuously without damage when fully submerged
  • Thermoplastic Impeller
  • Easily pass solids up to 1/2"
  • Carbon, Ceramic, BUNA & Stainless Steel Mechanical Seal
  • Provides superior abrasion resistance
  • 1-1/2" NPT Discharge
  • Will replace most pumps without any plumbing changes
  • Stainless Steel Fasteners
  • Helps extend the lifespan of the pump
  • 20' SJTW Power Cord w/ 3-Prong Plug
  • Quick-disconnect design allows for easy service
  • 1-Year Limited Warranty
California residents see
Warning: This product can expose you to chemicals including Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

PE41M
specs product image PID-96946
General Information
Product Category
Sump Pump
Base
Base Material
Cast Iron
Min Sump Basin Size
18 Inch
Motor
Voltage
120 Volt
Running Amps
7.5
Thermal Protection
Yes
Power Cord Length
20 Feet
Oil Free Motor
No
Pump
Mechanical Seal Material
Ceramic Carbon
Housing Material
Cast Iron
Impeller Material
Plastic
Solids Handling Size
.5 inch
Handles Solids
Yes
Float Type
No Switch
GPH @ 0 feet
3660
GPH @ 5 feet
3660
GPH @ 10 feet
3420
GPH @ 15 feet
2760
GPH @ 20 feet
1980
Discharge Port Size
1-1/2 Inch
Check Valve Included
No
Max Head
29 Feet
Engine
Horsepower
.4 HP
Overview
Product Category
Sump Pump
Weight
31 Pounds
Made in USA
Yes
Consumer Warranty
1 Year
Product Length
9.6 Inches
Product Width
6.4 Inches
Product Height
12.1 Inches
UPC
697666225801
