Goulds GSP Series - 1/2 HP Cast Iron Sump/ Effluent Pump (Non-Automatic)

Model:

GSP0511M

Write A Review
Add to Cart for Price
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
In-Stock
Ships Friday, Nov 22nd
Shipping to60601

Goulds GSP Series - 1/2 HP Cast Iron Sump/ Effluent Pump (Non-Automatic)
Goulds GSP Series - 1/2 HP Cast Iron Sump/ Effluent Pump (Non-Automatic)
Model: GSP0511M
Add to Cart for Price
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

Sump Pumps Direct expert image
Expert Recommended Accessories Selected by Jim, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Style

Primary

GPH

4260 Gallons

Switch Type

None

  • ***NON-AUTOMATIC - Requires Float Switch or Controller***
  • Goulds GSP Series Automatic Submersible Sump / Effluent Pump
  • Idea for residential sump and effluent applications
  • Heavy-Duty Cast Iron Housing
  • Robust design provides maximum heat dissipation
  • 1/2 HP Engineered Motor
  • Oil-filled and thermally protected design
  • Made for peak hydraulic performance without overloading
  • Vortex Style, Thermoplastic Impeller
  • Helps resist clogging & can pass solids up to 1/2"
  • Silicon Carbide / Carbon / BUNA Mechanical Seal
  • Provides exceptional protection for maximum pump life
  • Cast Iron Base, Volute & Strainer
  • Helps minimize corrosion in harsh sump conditions
  • Full-Base Suction Strainer
  • Keeps large debris from entering pump volute
  • 1-1/2" NPT Discharge
  • Will replace most sump pumps without any plumbing changes
  • Stainless Steel Fasteners, Handle & Float Bracket
  • Rugged design that helps prevent corrosion
  • 15' SJTW Power Cord w/ 3-Prong Plug
  • Meets the needs of residential applications
  • 2-Year Limited Warranty
California residents see
Warning: This product can expose you to chemicals including Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

GSP0511M
specs product image PID-96933
General Information
Product Category
Sump Pump
Base
Base Material
Cast Iron
Min Sump Basin Size
12 Inch
Motor
Voltage
120 Volt
Running Amps
8
Thermal Protection
Yes
Power Cord Length
9 Feet
Oil Free Motor
No
Pump
Mechanical Seal Material
Silicon Carbide
Housing Material
Cast Iron
Impeller Material
Plastic
Solids Handling Size
.5 inch
Handles Solids
Yes
Float Type
No Switch
GPH @ 0 feet
4260
GPH @ 5 feet
4260
GPH @ 10 feet
4260
GPH @ 15 feet
3360
GPH @ 20 feet
2280
Discharge Port Size
1-1/2 Inch
Check Valve Included
No
Max Head
26 Feet
Submersible
Yes
Engine
Horsepower
.5 HP
Overview
Product Category
Sump Pump
Weight
40 Pounds
Consumer Warranty
2 Years
Product Length
10.55 Inches
Product Width
7.55 Inches
Product Height
12 Inches
UPC
697666886088
